Nanjing Cetu Surveying Instrument Co., Ltd.
|
| Brand Name: | CETU |
| MOQ: | 1 |
| Price: | $800-30000 |
| Payment Terms: | T/T advance; Western union; MoneyGram,etc. |
| Supply Ability: | 1000 |
1. New stand design
2. New fast digital distance measuring head
3. 32-bit microprocessor
4. Optimize software operation process
5. 6-line LCD display
6. One-key quick measurement
7. SD card storage
| Telescope | |
| Imaging | Positive |
| Magnification | 30X |
| Objective Lens Effective Aperture | 50mm |
| Resolution | 3.75'' |
| Field Angle | 1°30′ |
| Shortest Sight Distance | 1m |
| Angle Measurement | |
| Angle Measure Method | Absolute Encode |
| Angle Measure Precision | 2″ |
| Minimum reading | 1″,5″ |
| Distance Measurement | |
| Precision | ±(2mm+2×10-6·D) |
| Distance Measurement | 8′/2mm |
| Compensation | |
| System | Liquid capacitive |
| Working Range | ±3′ |
| Resolution | 1″ |
| Plummer (Laser & Optical Optional) | |
| Optical Plummer | |
| Imaging | Positive |
| Magnification | 3X |
| Focus range | 0.3m~∞ |
| Field Angle | 5° |
| Laser Plummer | |
| Laser Wavelength | 650nm |
| Laser Power | 5mw |
| Laser Level | II |
| Effective Range | 0~3m |
| Spot Size | 1mm/1.5m |
| Battery | |
| Power Source | Rechargeable NiMH Battery |
| Voltage | DC 6V |
| Continous Working Time | BDC1800mAh About 10 hours |
| Temperature | |
| Working Temperature | -20ºC~+45ºC |
| Size & Weight | |
| Size | 180X166X355mm |
| Center High | 232mm |
| Weight | 6.5kg |
